• The engine is 6373 cc DE170 BS3, producing power of 170 KW(231hp) @ 2200 and a maximum torque 810 Nm @ 1200-1600 rpm.
  • The engine is coupled with G 85, 6 speed (6F+1R), with cable shift gearbox offering superior mileage.
  • The wheelbase of 5775 mm allows this BharatBenz truck to offer load body length suitable for different kinds of applications.
  • Air Brakes, Exhaust Brakes and Engine Brakes offer superior safety and the Parabolic leaf springs suspension in front offers good ride quality and Fatigue free driving.
  • Unitized FIP enhance better fuel mileage
Want To Know More? Call Us now - 9802917336
  • Technical Specification

    BharatBenz 3123R is a truck with gross vehicle weight of 31,000 kg. The engine powering this BharatBenz truck is 6373 cc DE170BS3, producing 230 HP of power and 810 Nm of maximum torque. The engine of the BharatBenz 3123R truck is coupled with a 6 speed manual (6F+1R), With cable shift gearbox offering superior mileage. This BharatBenz 3123R truck comes in an 8x2 axle configuration. The wheelbase of 5775 mm, allows this BharatBenz truck to offer load body length suitable for different kinds of applications. Air Brake and Engine Brake offers superior safety in BharatBenz 3123R and balancer type semi-elliptical leaf springs, with 2 hydraulic shock absorbers suspension in front offers good ride quality.

    Wheel Base 5775 6375
    Overall Length 9867 11067
    Overall Width 2490 2490
    Overall Height 2960 2960
    Rear Overhang 1957 2557
    Minimum ground Clearance 264 264
    Load Body Length 7300 (24 ft) 8500 (28 ft)
    Gross Vehicle Weight (GVW) 31,000 kg
    Model DE170BS3
    Maximum Power 170 kW (231hp) @ 2200 RPM
    Maximum Torque 810 Nm @ 1200 – 1600 rpm
    No. of cylinders, Displacement 6 Nos., 6373 cc
    Gear Box
    Gearbox Model & Type G 85 – 6F + 1R, Mechanical, Synchromesh Gears
    Clutch Type, Diameter Single dry plate, Hydraulic actuated, 395 mm
    Front Axle Model, Type VL4, Reverse Elliot & VD4, Pusher
    Rear Axle Model, Type RS4, Full floating, Hypiod gears
    Differential Ratio 5.875
    Chasis Frame & Suspension
    Chassis Type Channel Section with cross member
    Depth x Flange Width x Thickness 284 mm x 70 mm x 7mm
    Front Suspension Parabolic type leaf spring with 2 hydraulic shock absorbers
    Pusher Axle Suspension Air bellow
    Rear Suspension Balancer type semi elliptic leaf spring
    Anti-roll Bar Standard on both axles
    Brakes & Tyres
    Service Brake Pneumatic, Foot Operated, Dual Line
    Parking Brake Hand control valve acting on rear axle
    Wheel Rims & Tyre 7.5″ x 20″ & Radial 10.00 R 20- 16 PR/ (Optional) Crossply 10.00 x 20 – 16PR
    Steering & Cabin
    Steering Type Hydraulic Power Assisted
    Cabin Sleeper Cabin with Berth, Tiltable
    Fuel Tank & Electrical
    F.I.P. Unitized
    Fuel Tank 380 liters
    Voltage 24 V Electrical System
    Battery Capacity 2 x 12V, 120 Ah
    Maximum Gradability 18.3%
    Maximum Grade Speed 90 km/h
    Minimum Turning Circle Diameter 7300-21.6m | 8500-23.2m
    Standard Cabin & Chassis
    Load Body Option Fixed Side Deck & High Side Deck
    Option Packs Comfort Pack (HVAC), Hazardous Goods Pack & High CG Pack
